POWER PROBE · PPEVTEST

Electrical Vehicle Safety Tester

Electrical Vehicle Safety Tester

Gain deeper insight into EV insulation and electrical integrity.

$1,269.95
$1,269.95
Sale Sold out
Shipping calculated at checkout.
  • Evaluate insulation condition with dedicated resistance tests.
  • Measure low resistance with four-wire Kelvin testing.
  • Save test results and download stored data with Power Probe Link.
Product description

The Power Probe EV Tester is the perfect tool for any electric vehicle (EV) technician, designed to streamline and enhance the process of EV repair and maintenance. This all-in-one multimeter combines multiple essential testing functions, eliminating the need for multiple separate tools. Whether you're performing voltage measurements, insulation testing, or precise resistance checks, the EV Tester has you covered. With its advanced features, ECE-R100 compliance, and user-friendly design, it is the ultimate tool for professional EV diagnostics and maintenance.

Technical specifications

• TRUE RMS
• 4,000 counts
• TFT screen 2,8”
• Backlight
• Voltage up to 1.000VAC/DC
• Resistance (2W) up to 40kΩ
• Resistance (4W) up to 40Ω, minimum resolution of 1mΩ
• Insulation resistance test up to 1.000VDC
• PI, DAR calculation
• Short circuit test current ≤ 2mA
• Diode test
• Capacitance up to 10μF
• Temperature up to 400ºC/752ºF
• Auto power OFF
• Internal memory of 400 positions
• Bluetooth communication to PowerProbe Link App
• CAT IV 600V, CAT III 1000V

What’s included

• Test leads
• Alligator Clip set
• Insulation remote probe
• 4W (Kelvin) probe
• K-Type Thermocouple
• 4 x AA Alkaline batteries
• User manual
• Carrying bag

User Manual
View user manual (opens in a new tab)
Shipping & returns

Shipping policy

Returns policy

View full details

More insight into EV electrical systems

Advanced insulation testing

Assess insulation with Polarization Index, Dielectric Absorption Ratio, and timed test modes.

Four-wire resistance measurement

Measure low resistance with resolution down to 0.001 mΩ.

Bluetooth data transfer

Store up to 400 recordings per function and download saved results through Power Probe Link.
